Page 77 - CROWN_catalog_CAN_October_2021-22

Line laser Line laser
CT44063 CT44064
• Green laser • Green laser
• Laser class 2 • Laser class 2
• 5 lines projection mode • 5 lines projection mode
• Automatic self-levelling • Automatic self-levelling
• Unlevelled signal • Unlevelled signal
• Suitable for Outdoor / Indoor applications • Suitable for Outdoor / Indoor applications
• 360° rotation with fine adjustable knobs • 360° rotation with fine adjustable knobs
• 5/8” screw thread for tripod connection • 5/8” screw thread for tripod connection

4V, 1H 4V, 1H

Laser wavelength 515 nm Laser wavelength 520 nm
Levelling accuracy ±0,2 mm/m Levelling accuracy ±0,2 mm/m
Self-leveling range ±3° Self-leveling range ±3°
Power supply 4xAA or Li-lon or adapter Power supply 4xAA or Li-lon or adapter
Weight 1,15 kg Weight 1,43 kg

Line laser Rotary line laser
CT44065 CT44068

• Red laser • Red laser
• Laser class 2 • Laser class 2
• 3x360° projection mode • 2x360° rotary mode
• Automatic self-levelling • Automatic self-levelling
• Unlevelled signal • Unlevelled signal
• Suitable for Outdoor / Indoor applications • Suitable for Outdoor / Indoor applications
• Shield warning function and use for tilt purpose applications up to Ø240 m
• Continuos/pulse laser mode • Adjustable rotation speed
• Base 5/8” and 1/4” screw thread for tripod • Shockproof design with rubber protection
connection • 5/8” screw thread for tripod connection
• Additional bracket included • Additional bracket (accessory)

3 x 360° - 2V, 1H 2 x 360° - Rotary mode
Laser wavelength 635 nm Laser wavelength 635 nm
Levelling accuracy ±0,3 mm/m Levelling accuracy ±0,3 mm/m
Self-leveling range ±3° Self-leveling range ±3°
Power supply 4xAA or Li-lon or adapter Rotation speed 800/500/200 RPM
Weight 0,88 kg Power supply Ni-MH recharg. or 4xAA
Weight 1,5 kg

77
