Inverter DC MMA welding machine Inverter DC MMA welding machine
CT33100 CT33101
• MMA welding technology • MMA welding technology
• IGBT technology • IGBT technology
• Temperature protection • Temperature protection
• Current control • Current control
• Hot start function • Hot start function
• Welding current meter • Welding current meter
• Arc force

30-200 A 20-270 A

Rated input voltage 160-265 V Rated input voltage 130-560 V
Rated frequency 50/60 Hz Rated frequency 50/60 Hz
Rated input capacity 9,9 kVA Rated input capacity 13,8 kVA
Rated output voltage 21,2-28 V Rated output voltage 20,8-30,8 V
No-Load voltage 80 V No-Load voltage 220 V / 380 V 83 V / 66 V
Welding electrode diameter 2,5-4 mm Welding electrode diameter 2,5-5 mm
Rated duty cycle 40% Rated duty cycle 30%
Efficiency 83% Efficiency 83%
Weight 5,9 kg Weight 14,7 kg

Inverter DC MMA welding machine Inverter DC MMA welding machine
CT33125 (MMA-250D) CT33139 (MMA-300)

• MMA welding technology • MMA welding technology
• IGBT technology • IGBT technology
• Temperature protection • Temperature protection
• Current control • Current control
• Hot start function • Hot start function
• Easy start • Easy start
• Welding current meter • Welding current meter
• Arc force • Arc force

20-160 A 30-260 A

Rated input voltage 220-380 V Rated input voltage 220 V
Rated frequency 50/60 Hz Rated frequency 50/60 Hz
Rated input capacity 8,5 kVA Rated input capacity 13,3 kVA
Rated output voltage 20,8-26,4 V Rated output voltage 21,2-30,4 V
No-Load voltage 220 V / 380 V 101V / 86 V No-Load voltage 65 V
Welding electrode diameter 1,6-4 mm Welding electrode diameter 1,6-5 mm
Rated duty cycle 35% Rated duty cycle 25 %
Efficiency ≥78 % Efficiency ≥78 %
Weight 6 kg Weight 9,7 kg

Inverter DC MMA welding machine Inverter DC MMA welding machine
CT33124 (MMA-315D) CT33126 (MMA-400)

• MMA welding technology • MMA welding technology
• IGBT technology • IGBT technology
• Temperature protection • Temperature protection
• Current control • Current control
• Hot start function • Hot start function
• Easy start • Easy start
• Welding current meter • Welding current meter
• Arc force • Arc force

20-180 A 30-300 A
Rated input voltage 220-380 V Rated input voltage 220 V
Rated frequency 50/60 Hz Rated frequency 50/60 Hz
Rated input capacity 12,2 kVA Rated input capacity 15,4 kVA
Rated output voltage 20,8-27,2 V Rated output voltage 21,2-32 V
No-Load voltage 220 V / 380 V 101V / 86 V No-Load voltage 75 V
Welding electrode diameter 1,6-4 mm Welding electrode diameter 1,6-5 mm
Rated duty cycle 30% Rated duty cycle 25 %
Efficiency ≥78 % Efficiency ≥78 %
Weight 6 kg Weight 13,5 kg
