Page 71 - CROWN_catalog_CAN_October_2021-22

Laser measure Laser measure
CT44032 CT44033

• Laser class 2 • Laser class 2
• Units selection • Units selection
• Type of measure • Type of measure
• Reference point • Reference point
• Calculating • Calculating
• Memory • Memory
• Level sensor • Level sensor
• LCD screen • LCD screen

0,05 m - 40 m 0,05 m - 60 m

Measuring accuracy ±2 mm Measuring accuracy ±2 mm
Time of single measurement 0,25 s Time of single measurement 0,25 s
Laser type 650 nm Laser type 650 nm
Laser grade class II Laser class II, <1 mW
Operating temperature range 0 ... +40 °C Operating temperature range 0 ... +40 °C
Storage temperature range -20 ... +65 °C Storage temperature range -20 ... +65 °C
Battery type 2 x 1,5V ААА Battery type 2 x 1,5V ААА
Weight 0,107 kg Weight 0,107 kg

Laser measure Laser measure
CT44034 CT44035

• Laser class 2 • Laser class 2
• Units selection • Units selection
• Type of measure • Type of measure
• Reference point • Reference point
• Calculating • Calculating
• Memory • Memory
• Level sensor • Level sensor
• LCD screen • LCD screen

0,05 m - 80 m 0,05 m - 100 m
Measuring accuracy ±2 mm Measuring accuracy ±2 mm
Time of single measurement 0,25 s Time of single measurement 0,25 s
Laser type 650 nm Laser type 650 nm
Laser class II, <1 mW Laser class II, <1 mW
Operating temperature range 0 ... +40 °C Operating temperature range 0 ... +40 °C
Storage temperature range -20 ... +65 °C Storage temperature range -20 ... +65 °C
Battery type 2 x 1,5V ААА Battery type 2 x 1,5V ААА
Weight 0,107 kg Weight 0,107 kg

Laser measure Laser measure

CT44066 CT44067
• Laser class 2 • Laser class 2
• Suitable for Outdoor / Indoor applications • Suitable for Outdoor / Indoor applications
• Pythagorean function • Pythagorean function
• Able to store up to 10 measured datas • Able to store up to 10 measured datas
• Maximum/minimum measurement, area • Maximum/minimum measurement, area
calculation, volume calculation, volume
• calculation, add and subtract function, time • calculation, add and subtract function, time
delay measurement delay measurement
• Self Illuminated large LCD display • Self Illuminated large LCD display

40 m 40 m
Measuring accuracy ±3 mm Measuring accuracy ±2 mm
Laser wave length 635 nm Laser wave length 520 nm
Laser class II, <1 mW Laser class II, <1 mW
Battery type 2 x 1,5V ААА Battery type 3.7 V Li-ion 980 mAh
Weight 0,07 kg Weight 0,12 kg

71
