Page 54 - CROWN_catalog_CAN_October_2021-22

Cut-off saw Cut-off saw
CT15232 CT15205N

• Spindle lock • Spindle lock
• Mitre angular adjustment • Mitre angular adjustment
• Carriage position • Carriage position
• Lock-off function • Lock-on function

2200 W 2200 W

Amperage at voltage 220-230 V 10.6 A Amperage at voltage 220-230 V 10.3 A
Max. Ø of cutting disc 355 mm Max. Ø of cutting disc 355 mm
No-load speed 3900 minˉ¹ No-load speed 3800 minˉ¹
Bore Ø of cutting disc 25,4 mm Bore Ø of cutting disc 25,4 mm
Max. thickness of cutting disc 3,5 mm Max. thickness of cutting disc 3,5 mm
Maximum size of cut-off workpiece: - Maximum size of cut-off workpiece: -
workpiece (Ø; cutting at 0° / 45°) 130 / 110 mm workpiece (Ø; cutting at 0° / 45°) 110 / 90 mm
workpiece (L × H; cutting at 0° / 45°) 115 x 115 / 90 x 90 mm workpiece (L × H; cutting at 0° / 45°) 95 x 95 / 90 x 90 mm
workpiece (L × H, cutting at 0° / 45°) 205 x 95 / 100 x 85 mm workpiece (L × H, cutting at 0° / 45°) 70 x 180 / 60 x 110 mm
workpiece (L × H, cutting at 0° / 45°) 140 x 140 / 85 x 85 mm workpiece (L × H, cutting at 0° / 45°) 95 x 95 / 90 x 90 mm
Weight 18,25 kg Weight 14,5 kg

Multi-function tool Jigsaw
CT16004 CT15212
CT16004 BMC • Stroke rate regulation
• 4-stage pendulum
• Special accessories connection • Angular adjustment
• Variable speed • Saw blade easy change
• Rotation speed stabilization system • Lock-on function
• Soft start • Dust extraction system

320 W 550 W
Amperage at voltage 220-230 V 1.53 A Amperage at voltage 220-230 V 2.4 A
No-load speed 6000-20000 minˉ¹ Stroke rate at no-load 700-3000 minˉ¹
No-load oscillations rate 3,2° Stroke length 18 mm
Sanding plate diameter 80 mm Cutting ability in wood 65 mm
Weight 1,68 kg Cutting ability in aluminum 10 mm
Cutting ability in steel 6 mm
Max. angularity of the body (left / right) 45°/45°
Weight 1,9 kg

Jigsaw Sabre saw

CT15189 CT15263
• Stroke rate regulation • Electronic speed adjustment
• 4-stage pendulum • Saw blade easy change
• Angular adjustment • Lock-on function
• Saw blade easy change • Rear D-handle
• Lock-on function • Soft grip
• Dust extraction system
• Soft grip

710 W

Amperage at voltage 220-230 V 3.1 A 500 W
Stroke rate at no-load 700-3000 minˉ¹
Stroke length 26 mm Amperage at voltage 220-230 V 2.1 A
Cutting ability in wood 85 mm Stroke rate at no-load 0-3500 minˉ¹
Cutting ability in aluminum 20 mm Stroke length 15 mm
Cutting ability in steel 10 mm Cutting ability in wood 80 mm
Max. angularity of the body (left / right) 45°/45° Cutting ability in steel (profile / pipe) 5 /50 mm
Weight 2,9 kg Weight 1,5 kg
